MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 33/ 109
3.3. Front panel LCD Menu operation
3.3.1. Basic concept
There are three operation modes of the LCD menu:
Normal mode Most settings can be done in this mode. It activates after
powering on.
EDID mode Use this mode to set up the emulated EDID on the inputs,
learn EDID form the outputs or to view the EDID memory.
This mode is activated when EDID button is illuminated.
You can enter this mode or exit by pressing the EDID
button.
Signal present mode This mode is for checking the presence of the display
devices and incoming signals. It is activated when
SIGNAL PRESENT button is illuminated. You can enter
this mode or exit by pressing SIGNAL PRESENT button.
Press the LEFT or the RIGHT button to jump between the menus and parameters
Use the ENTER or TAKE buttons to enter a menu or execute an item. The UP and
DOWN buttons modify the values if modification is enabled.
LCD menu
Normal mode
Default display
IP settings
IP address
IP port
IP subnet
IP gateway
Power status
Installed cards
Firmwares
Factory resets
IP reset
IO card reset
HDCP reset
EDID reset
EDID mode
Edid view
Edid save
EDID switch
Signal present mode
LCD menu structure
