3.2.4. SAVE or LOAD PRESETS
The unit has 32 user programmable presets. Each preset stores a configuration
regarding all input connections for all outputs. All presets are stored in a non-
volatile memory. The router keeps presets even in case of power down. Memory
numbers are assigned to source buttons. (1 to 32 in MX32x32 frame, 1 to 16 in
MX16x16 frame or 1 to 8 in the MX8x8 family.
Saving a Preset in TAKE mode
1. Press and release SAVE PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
32 or to 16)
3. Press and release TAKE button. Now the current configuration is stored in
selected memory.
Info: Preset save action always stores the current configuration for all outputs.
Loading a Preset in TAKE mode
1. Press and release LOAD PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
32 or to 16)
3. Press and release TAKE button. Now the selected preset is loaded.
Info: Loading a preset always modifies all output states.
Saving a Preset in AUTOTAKE mode
1. Press and release SAVE PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
32 or to 16). Now the current configuration is stored in the selected memory.
Info: Preset save action always stores the current configuration for all outputs.
Loading a Preset in AUTOTAKE mode
1. Press and release LOAD PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
32 or to 16). Now the selected preset is loaded.
Info: Loading a preset always modifies all output states.
