6.6.2. Static IP address configuration
The user can manually assign an IP address to the unit, and enter related network
settings.
To assign an IP address manually:
Step 1 Click on Configuration menu
Step 2 Select Network Settings
Step 3 Select Fix IP Configuration
Step 4 Enter the following (as necessary):
If DHCP is not used to assign IP addresses,
enter it manually in decimal-dot notation. The
IP ad
dresses must be set to a unique value
A subnet mask defines the number of bits
taken from the IP address that are assigned
The gateway address, or router, allows
communication to another LAN segments.
The gateway address should be the IP
address of the router connected to the same
LAN segment as the matrix. The gateway
address must be within the local network.
When you are finished, click Apply Settings button
Info: To continue using the Web Manager, you must type the new IP address in the
browser.
6.6.3. Loading the default IP settings
Step 1 Click on the Load Default button. Now the factory default
IP address, Subnet Mask and Gateway address is loaded
into the input boxes. However, they are not saved.
Step 2 To save the settings, click on Apply Settings button.
6.6.4. TCP Port Configuration
The user can configure the TCP port number, which is used to communicate with
the matrix router through LAN. The input box initially contains the current setting.
Step 1 Type the desired TCP port number into the input box
Step 2 Press the Apply Settings button. The new port will be
active after the next connection.
