2.8. Electrical connections
2.8.1. Signal inputs
MX32x32DVI-HDCP-Pro, MX16x16DVI-HDCP-Pro and MX8x8DVI-HDCP-Pro
provide 29-pole DVI connectors for input connections, however only digital signal
pins are connected. Always use high quality DVI cables to connect sources and
displays.
Pin Signal Pin Signal Pin Signal
1
TMDS Data2-
9
TMDS Data1-
17
TMDS Data0-
2
TMDS Data2+
10
TMDS Data1+
18
TMDS Data0+
3
TMDS Data2 Shield
11
TMDS Data1 Shield
19
TMDS Data0 Shield
4
nc
12
nc
20
nc
5
nc
13
nc
21
nc
6
DDC Clock
14
+5V Power
22
TMDS Clock Shield
7
DDC Data
15
GND (for +5V)
23
TMDS Clock+
8
nc
16
Hot Plug Detect
24
TMDS Clock-
DVI connector Single Link pin assignment
MX32x32HDMI-Pro, MX16x16HDMI-Pro, and MX8x8HDMI-Pro provide 19-pole
type A HDMI connectors for input connections.
Pin Signal Pin Signal
1
TMDS Data2+
2
GND
3
TMDS Data2-
4
TMDS Data1+
5
GND
6
TMDS Data1-
7
TMDS Data0+
8
GND
9
TMDS Data0+
10
TMDS Clock+
11
GND
12
TMDS Clock-
13
nc
14
nc
15
SCL
16
SDA
17
DDC/CEC GND
18
+5V Power
19
Hot Plug Detect
HDMI connector pin assignment
