Lightware MX8x8HDMI-PRO User Manual

MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 47/ 109
4.2.4. View Router’s health
Description: Shows power, temperature and fan status of the router.
Legend:
Example:
MX32x32
→ {ST}
← (STAT 3.2V 5.0V 12.1V 23C 1629RPM 1600RPM)CrLf
MX16x16
→ {ST}
← (STAT 3.2V 5.0V 12.1V 23C 1629RPM 1600RPM CrLf
MX8x8
→ {ST}
← (STAT 3.2V 5.0V 23C)CrLf
4.2.5. View Installed I/O cards’ hardware
Description: Shows the hardware name and revision of the installed cards.
Example
:
MX32x32
→ {IS}
←
←
←
←
←
←
←
←
←
(SL#
●0●MB_DESCRIPTOR)CrLf
(SL#
●1●OUTPUT_CARD_DESC)CrLf
(SL#
●2●OUTPUT_CARD_DESC)CrLf
(SL#
●3●OUTPUT_CARD_DESC )CrLf
(SL#
●4●OUTPUT_CARD_DESC)CrLf
(SL#
●5●INPUT_CARD_DESC)CrLf
(SL#
●6●INPUT_CARD_DESC)CrLf
(SL#
●7●INPUT_CARD_DESC)CrLf
(SL#
●8●INPUT_CARD_DESC)CrLf
MX16x16
→ {IS}
←
←
←
←
←
←
←
←
←
(SL#
●0●MB_DESCRIPTOR)CrLf
(SL#
●1●OUTPUT_CARD_DESC)CrLf
(SL#
●2●OUTPUT_CARD_DESC)CrLf
(SL#
●3●EMPTY_SLOT)CrLf
(SL#
●4●EMPTY_SLOT)CrLf
(SL#
●5●INPUT_CARD_DESC)CrLf
(SL#
●6●INPUT_CARD_DESC)CrLf
(SL#
●7●EMPTY_SLOT)CrLf
(SL#
●8●EMPTY_SLOT)CrLf
MX8x8
→ {IS}
←
←
←
←
←
←
←
←
(SL#
●0●MB_DESCRIPTOR)CrLf
(SL#
●1●OUTPUT_CARD_DESC)CrLf
(SL#
●2●EMPTY_SLOT)CrLf
(SL#
●3●EMPTY_SLOT)CrLf
(SL#
●4●EMPTY_SLOT)CrLf
(SL#
●5●INPUT_CARD_DESC)CrLf
(SL#
●6● EMPTY_SLOT)CrLf
(SL#
●7●EMPTY_SLOT)CrLf
(SL#
●8●EMPTY_SLOT)CrLf
MX32x32
→ {IS}
←
←
←
←
←
←
←
←
←
(SL# 0 MX-DVI-MB32 SCH_1.1 PCB_1.1 )CrLf
(SL# 1 MX-DVI-HDCP-OB SCH_1.1 PCB_1.1)CrLf
(SL# 2 MX-DVI-HDCP-OB SCH_1.1 PCB_1.1)CrLf
(SL# 3 MX-DVI-HDCP-OB SCH_1.1 PCB_1.1)CrLf
(SL# 4 MX-DVI-HDCP-OB SCH_1.1 PCB_1.1)CrLf
(SL# 5 MX-DVI-HDCP-IB SCH_1.1 PCB_1.1)CrLf
(SL# 6 MX-DVI-HDCP-IB SCH_1.1 PCB_1.1)CrLf
(SL# 7 MX-DVI-HDCP-IB SCH_1.1 PCB_1.1)CrLf
(SL# 8 MX-DVI-HDCP-IB SCH_1.1 PCB_1.1)CrLf
MX16x16
→ {IS}
←
←
←
←
←
←
←
←
←
(SL# 0 MX-DVI-MB16 SCH_1.1 PCB_1.1)CrLf
(SL# 1 MX-HDMI-OB SCH_1.1 PCB_1.1)CrLf
(SL# 2 MX-HDMI-OB SCH_1.1 PCB_1.1)CrLf
(SL# 3 EMPTY SLOT)CrLf
(SL# 4 EMPTY SLOT)CrLf
(SL# 5 MX-HDMI-IB SCH_1.1 PCB_1.1)CrLf
(SL# 6 MX-HDMI-IB SCH_1.1 PCB_1.1)CrLf
(SL# 7 EMPTY SLOT)CrLf
(SL# 8 EMPTY SLOT)CrLf
MX8x8
→ {IS}
←
←
←
←
←
←
←
←
←
SL# 0 MX-DVI-MB8 SCH_1.1 PCB_1.1)CrLf
(SL# 1 MX-DVI-HDCP-OB SCH_1.1 PCB_1.1)CrLf
(SL# 2 EMPTY SLOT)CrLf
(SL# 3 EMPTY SLOT)CrLf
(SL# 4 EMPTY SLOT)CrLf
(SL# 5 MX-DVI-HDCP-IB SCH_1.1 PCB_1.1)CrLf
(SL# 6 EMPTY SLOT)CrLf
(SL# 7 EMPTY SLOT)CrLf
(SL# 8 EMPTY SLOT)CrLf
MX32x32
→ {ST}
←
(STAT●<V1>●<V2>●<V3>●<temp>●<rpm1>● <rpm2>)CrLf
MX16x16
→ {ST}
←
(STAT●<V1>●<V2>●<V3>●<temp>●<rpm1>● <rpm2>)CrLf
MX8x8
→ {ST}
←
(STAT●<V1>●<V2>●<temp>)CrLf
Identifier
description
default value
<V1>
System voltage
3.3V
<V2>
EDID voltage
5.0V
<V3>
FAN voltage
12V
<temp>
System Temp.in °C
24°C
<rpm1>
FAN1 speed
1600RPM
<rpm2>
FAN2 speed
1600RPM
