MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 51/ 109
fields:
PNPID code The three letter abbreviation of the manufacturer
Preferred resolution The resolution and refresh rate stored in the preferred
detailed timing block.
Name The name of display device stored in product descriptor.
Note: If a CEA extension is present in the EDID, HDMI capable sources such as top-
boxes and BD-players will use the short video descriptors instead of preferred
detailed timing block in order to determine the type of the sent video. Please refer
the standards for more details.
Example:
Show the emulated EDID on DVI input#1 (for more information see session EDID
Management: using EDID Router)
