LS SERIES SERVICE MANUAL
ISSUE 4.0 SPARE PARTS 2
14.3 Spares List
Note that new part numbers are now used: -
Battery Backed RAM (IC18) E06 - 493
(If this is replaced, its time MUST be set by running the NEXYGEN Plus 3 Console)
Full Control Console LCD Display SPK/LS/0044
Full Control Console Keypad KBT/0046/00
Full Control Console PCB 04/1460
Hand Held Remote Keypad KYS/0056/00
Hand Held Remote PCB including LCD Display SPK/LS/0045
Limit Microswitches SPK/LS/0036
Blind Assembly COV/0733/00
LS1 etc. Motor, Gearbox and Encoder SPK/LS/0006/A
LS2K5E and LS5S Motor, Gearbox and Encoder SPK/LS/0006/B
LS1 etc Drive Belt BLT/0450/00
LS2K5E Drive Belt BLT/0454/00
LS5S Drive Belt BLT/0453/00
Loadcell Amplifier (contained inside the loadcell plug) 04/1451
Main PCB SPK/LS/0005
Motor Drive PCB including Power Dump Resistor and Loom SPK/LS/0004/A
Fuse for Motor Drive PCB (T5AH250V) FLK/0013/00
Digital and Analogue Switch Mode Power Supply Unit SPK/LS/0042
External Loadcell Loom SPK/LS/0017
Main Console Loom SPK/LS/0018
USB Loom CBT/1357/00
Extensometer Adaptor Loom 09/1047
