LS SERIES SERVICE MANUAL
ISSUE 4.0 OVERVIEW 12
1.16 Optional Splinter Shield
An optional safety shield, part number 01/3909, may be used to enclose the testing machine
and this shield can be electrically interlocked to the motor drive system. This shield prevents
the user from contacting the moving crosshead or grips during a test and also prevents
fragments of broken sample from flying out of the work area.
The optional safety shield is supplied complete with the internal and external interlock looms
(09/1046 and 09/1051) so that it can be easily interlocked if required. If an electrical interlock
is not required, then the internal loom (09/1046) is not fitted inside the LS frame. See section
2.6 for details.
The user operating instruction manual provides complete specifications, control
functioning and operational data and should be referred to for this information.
