Lloyd LS1 - Setting the Extensometer Type and Serial Number

LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 10
NOTES:-
1 Although the loadcell overload circuit WILL protect the loadcell, it is advised that
the machine is NOT left RUNNING UNATTENDED during calibration.
2 A single calibration point may be deleted by pressing the key under DELETE when on the
VIEW POINTS screen.
3 All previous calibration points may be removed by pressing the key under CLEAR
POINTS then pressing the key under YES.
12.7 Setting the Extensometer Type and Serial Number
This should only be required if an extensometer has been converted for use with the
machine or if the extensometer EEPROM has been accidentally erased.
1 Press the key under > to display the second diagnostic screen shown below
Diagnostics
Slow Jog
Setup External 10
Machine Device mm/min >
2 Press the key under EXTERNAL DEVICE to display the "Extensometer Selection" screen.
Select External Device to Calibrate
XXXXX
< >
3 Select the required extensometer (if more than 1 extensometer is connected to the
machine) then press the ENTER key.
Calibrate External Device
Serial
Number Type Set Calibrate
XXXX XXXX Detail or Verify
4 Press the key under SERIAL NUMBER to display the "Change Serial Number" screen.
