LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 5
12.5 Checking the Loadcell Offset and Overloads
1 Press the key under LOADCELL to display the "Calibrate Loadcell" screen.
Calibrate Load Cell
Serial
Number Size Calibrate View
XXXX 1kN Or Verify Points
2 Press the key under VIEW POINTS to display the "View Loadcell Information" screen.
View Load Cell Information
Print View
Cal Last Cal Load
Points Overload Points Readings
3 Press the key under LAST OVERLOAD to display the "Loadcell Overloads" screen.
Load Cell Overloads
None
Today's Date 23/06/1999 14:56 UTC
4 If the loadcell has not been overloaded, the screen will display NONE.
5 If the loadcell has been overloaded, an entry is made in the "Loadcell Overloads" history
each time the load value exceeds 120% of the loadcell capacity, e.g. 1200N for a 1000N
loadcell.
6 The date and time (in UTC) of the last overload is also displayed together with the current
date and time.
Load Cell Overloads
Number of Overloads is 1
Last Overloaded on 11/01/1999 12:32 UTC
Today's Date 23/06/1999 14:56 UTC
7 If an overload has occurred, the loadcell should be visually checked to ensure that the eye
ends are still aligned. This is because a severe overload will bend the loadcell and make it
unusable. Note that if the loadcell is physically damaged, it must be replaced because a
loadcell is NOT repairable
8 Press the ENTER key to exit this screen.
9 Remove any grips from the loadcell.
