Lloyd LS1 - Setting the Machine Type and Serial Number

LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 3
12.3 Setting the Machine Type and Serial Number
This procedure is only required during initial installation or if the Motor Drive PCB has been
replaced.
1 Press the key under > to display the second diagnostic screen.
Diagnostics
Slow Jog
Setup External 25.00
Machine Device mm/min >
2 Press the key under MACHINE SETUP to display the "Setup Machine" screen.
Setup Machine
Serial Machine Default Set
Number Identity Units Machine
XXXX XXX Metric Detail
3 Press the key under SERIAL NUMBER to enter the Serial Number.
Change or Accept machine serial number
XXXX
BkSp Clear All
4 Enter the required Serial Number using the keypad then press the ENTER key to store
the value into EEPROM on the Motor Drive PCB.
5 Press the key under MACHINE IDENTITY to select the Machine Type.
Select machine identity
LS1
< >
6 The < and > keys scroll through list of machine types applicable to the embedded code
Version. Select the required machine then press the ENTER key to store the value.
Note that the FT1 requires different embedded code than the other machine types.
Also note that the machine will reboot so the Diagnostic mode will need to be
selected again if required.
