LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 4
7 The Default Units for a Stand-Alone test may be changed from METRIC (N & mm) to
IMPERIAL (lbf & in) by pressing the key under DEFAULT UNITS.
Note that the actual units for a Stand-Alone test are set using the SETUP function.
Note that the option of SET MACHINE DETAIL should NOT be selected because this is only for
special applications. If this option is accidentally selected, or any settings changed, the settings
can be reset to the default values by reselecting the correct machine type as shown above.
12.4 Changing the Loadcell Value and Serial Number
This should only be required if the loadcell EEPROM has been accidentally erased.
1 Press the key under LOADCELL to display the "Calibrate Loadcell" screen.
Calibrate Load Cell
Serial
Number Size Calibrate View
XXXX 1kN Or Verify Points
2 Press the key under SERIAL NUMBER to enter the Serial Number.
Change Or Accept Load Cell Serial Number
XXXXX
Bksp Clear All
3 Enter the required Serial Number using the keypad then press the ENTER key to store
the value into EEPROM on the Loadcell Amplifier PCB.
4 Press the key under SIZE to select the Loadcell Value.
Change Or Accept Load Cell Rating
1kN
< >
5 The < and > keys scroll through list of pre-programmed Loadcell values. Select the
required value then press the ENTER key to store the value.
