LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 16
12.10 Exporting and Importing Loadcell Data Points
The loadcell calibration points stored in the loadcell EEPROM may be exported to a PC, e.g. to
Windows Hyperterminal, for reference purposes. These values may be easily re-entered into the
loadcell EEPROM if the data becomes corrupt so the loadcell calibration can be reset without
having to use calibration equipment.
The data points can be exported by selecting the diagnostic mode then following the steps below.
1 Connect the RS232 cable to the PC and to the rear 9 pin socket of the machine.
2 Start Windows Hyperterminal and set the Baud Rate to 9,600 with 8 Data Bits, 1 Stop Bit
and No Parity.
3 Enter the diagnostic mode.
4 Select VIEW POINTS, select CAL POINTS then select PRINT CAL POINTS.
A report will be produced similar to that shown below: -
Lloyd Instruments Ltd
Machine Type LRX PLUS
Machine serial number 10123
Load Cell Size 5kN
Load Cell serial number 015318
Number of cal points 5
Cal Point Measured True
1 -32768 -32768
2 -26282 -26216
3 9 -1
4 26278 26212
5 32767 32767
To re-enter data points, select CAL POINTS then repeatedly press the > arrow until the option of
ADD is shown.
Select ADD, enter the TRUE value (DATA Y) then enter the MEASURED VALUE (DATA X).
Repeat until all the required points have been entered.
To Next Page
