LS SERIES SERVICE MANUAL
ISSUE 4.0 CONTENTS 4
11 DIAGNOSTIC MODES
11.1 General 1
11.2 Selecting the Diagnostic Mode 1
11.3 Loadcell Verification 2
11.4 Installing an External Extensometer 2
11.5 Converting an Analogue Extensometer 3
11.6 Converting an Encoder Extensometer 4
11.7 Extensometer Verification 4
11.8 PC Diagnostic Mode 4
12 FULL CONTROL CONSOLE DIAGNOSTICS
12.1 General 1
12.2 Selecting the Internal Diagnostic Mode 1
12.3 Setting the Machine Type and Serial Number 3
12.4 Changing the Loadcell Value and Serial Number 4
12.5 Checking the Loadcell Offset and Overloads 5
12.6 Loadcell Calibration 7
12.7 Setting the Extensometer Type and Serial Number 10
12.8 Calibrating an Analogue Extensometer 11
12.9 Calibrating an Encoder Extensometer 14
12.10 Exporting and Importing Loadcell Data Points 16
13 NEXYGEN PLUS 3 DIAGNOSTICS
13.1 General 1
13.2 Selecting the NEXYGEN Plus 3 Diagnostic Mode 1
13.3 Setting the Machine Type and Serial Number 3
13.4 Changing the Loadcell Value and Serial Number 3
13.5 Checking the Loadcell Offset and Overloads 4
13.6 Loadcell Calibration 7
13.7 Setting the Extensometer Type and Serial Number 11
13.8 Calibrating an Analogue Extensometer 12
13.9 Calibrating an Encoder Extensometer 14
