10.3. Process of editing and running the program
10.3.1. Creating or opening a file
Clicking on the block of file name to pop up operation page of program files, through which to
create, save, and open the program files.
10.3.2. "Record" continuous track and IO motion
1. Switch to teaching mode and click Record
2. Move the robot to the target position with a button
or handwheel
3. Set "Select coordinate system"
4. Click on the line or other action command
5. Repeat steps 2~4 to complete the action flow.
Program
display mode
Number of
workpiece
s
Number of
workpieces
Operation mode
One round /
repeat
Run from
the current
Starting
program
