15. NC Editing
This page is suitable for short modifications to the program. If you need lots of writing, it is
recommended to write at PC and then pass it to the controller.
15.1. Types of files
Save
location
NCFiles Folder Macro Folder Macro Folder
Rules of
file names
Arbitrarily maker_macro_g1000 maker_func_ins_macro1000
NC
executing
page
Name of Start files Start No.
External
executing
mode
R17022~R17029=File
name
R23030=1
C0=1
R17004=1000
C22=1
Files operation View mode
Software
keyboard
Operation of program lines
