Lorex D231A41B User Manual

Pan/Tilt/Zoom (PTZ) Cameras16
4. Tour: Perform the tour number specified in the No. field. For instructions on creating a tour,
see 16.5 Tours, page 77.
5. Flip: Rotate the camera 180° from its current position.
6. Pattern: Perform the pattern number specified in the No. field. For instructions on creating
a pattern, see 16.6 Patterns, page 77.
7. Reset: Move the camera to the home position.
8. AutoScan: Move the camera between a predetermined left and right point. For instructions
on creating an autoscan, see 16.7 AutoScan, page 78.
9. Configuration: Click to open the configuration menu, where you can configure presets,
tours, patterns and autoscans.
10. OSD Menu: Click to open the camera’s OSD menu. This may not be supported on all cam-
era models.
11. Auxiliary Settings: Not supported.
16.4 Presets
Presets will save a camera position for quick retrieval.
To add preset locations:
1. From the Live View display of your PTZ camera, right-click to open the Quick Menu, then
click Pan/Tilt/Zoom.
2. The PTZ controls open. Click
to open advanced PTZ controls, then click .
3. Click the Preset tab.
4. Enter the number of the preset you want to create under Preset.
5. Move the camera to the desired position and click Set.
To go to a preset location:
• Under No., select the number of the preset you want to go to, then click
.
16.5 Tours
Tours will cycle through a set of presets.
To add tours:
1. From the Live View display of your PTZ camera, right-click to open the Quick Menu, then
click Pan/Tilt/Zoom.
2. The PTZ controls open. Click
to open advanced PTZ controls, then click .
3. Click the Tour tab.
4. Under Patrol No., enter the number of the tour you want to create.
5. Under Preset, select a preset you want to add to the tour.
6. Click Add Preset.
7. Repeat steps 5 & 6 to add additional presets to the tour.
To run a tour:
• Under No., select the number of the tour you want to go to, then click
.
16.6 Patterns
Patterns automatically move the camera according to manually-entered movements.
To add patterns:
1. From the Live View display of your PTZ camera, right-click to open the Quick Menu, then
click Pan/Tilt/Zoom.
2. The PTZ controls open. Click
to open advanced PTZ controls, then click .
3. Click the Pattern tab.
4. Under Pattern, enter the number of the pattern you want to create.
#LX400111; r. 3.0/56507/56507; en-US 77
