Replacing the Hard Drive18
The system comes with a pre-installed 3.5" SATA hard drive. You can replace the hard drive
with one up to a maximum size of 10TB.
18.1 Removing the Hard Drive
CAUTION
Make sure that the system is OFF and the power adapter is disconnected before removing/installing a hard drive.
To remove the hard drive:
1. Power off the system, and unplug all cabling from the system.
2. Turn the recorder over. Remove the bottom panel screws (6×).
3. Turn the recorder over carefully, then remove the top panel.
CAUTION
The wiring to the front panel button and USB port runs along the top panel of the recorder. When separating
the top panel, rest it carefully beside the bottom panel as shown below.
#LX400111; r. 3.0/56507/56507; en-US 82
