Motion Detection11
In addition to general motion detection, the system supports smart Person/Vehicle detection.
Both types of detection can be configured using the menu shown below.
11.1 Configuring Motion Detection
Set preferences for motion detection on each channel, and select channels you want to enable
smart Person/Vehicle detection on.
CAUTION
A maximum of 1channel will support Person/Vehicle detection at once. By default, channel 1 has Person/Vehicle
detection enabled.
To configure motion detection:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click ALARM. Click the MOTION tab on the side panel, then Motion Detect on the top
panel.
3. Select a channel to configure motion detection for.
4. Click to enable (
) / disable ( ) motion detection on the selected channel.
#LX400111; r. 3.0/56507/56507; en-US 32
