LNR600 Series Hard Drive Installation
20
3. Turn the system over and loosen the hard drive screws (4x), but do not remove them.
4. Disconnect the SATA power and data cable from the hard drive.
5. Carefully turn the system over. Slide the hard drive and then lift it out of the system.
6. Replace the cover and cover screws (4x).
NOTE
After installation, you must format the hard drive in order to use it with the system. See 20.3 Format-
ting Hard Drives, page 147.
20.3 Formatting Hard Drives
You must format hard drives before you may use them with the system.
#LX400078; r.36882/36882; en-US
147
