Using the System
8
Use the system’s graphical on-screen display to navigate menus and configure options
and settings.
8.1 On-Screen Display
The system shows the following for all display views:
1. Display area:
• Click on a channel to view in full-screen; click again to return to split screen.
• Right-click to open the Quick Menu.
• Hover the mouse cursor over the bottom of the screen to open the Navigation Bar.
Move the mouse cursor away from the bottom of the screen to close the navigation
bar.
• Move the mouse to the top of a channel to view the Camera Toolbar.
• Click-and-drag cameras to rearrange the channel display. This does not affect the
channels each camera is connected or recording to.
2. Channel name
3.
: Camera is continuously recording.
4.
: Motion has been detected and video is recording.
5.
: Motion has been detected but video is not recording.
6. Date & time: Current system date and time. For details on setting the date and time,
see 9 Setting The Time, page 23.
#LX400078; r.36882/36882; en-US
16
