Lorex LNR600 Series User Manual

LNR600 Series System
Specifications
23
23.1 System
Operating System Linux (embedded)
Pentaplex
Simultaneous View, Record, Playback, Backup &
Remote Monitoring
Number of Channels 8/16 Channels
23.2 Inputs/Outputs
Video IN 8ch: 8 PoE Video Input
16ch: 16 PoE Video Input
Video OUT
No
VGA OUT Yes
HDMI Yes
Audio IN
1 Line IN (RCA) for service only
Audio OUT 1 Line OUT (RCA) for service only
USB Port 1 at the back, 1 at the front
Alarm IN 4 Alarm IN
Alarm OUT 2 Alarm OUT
Video Output Resolution
3840×2160, 1920×1080, 1280×1024, 1280×720,
1024×768
PTZ Control Lorex IP PTZ cameras only
23.3 Display
Display Split 8 ch: 1/4/8
16 ch: 1/4/8/9/16
Live Display Speed 8 ch: 240fps NTSC / 200fps PAL
16 ch: 480fps NTSC, 400fps PAL
OSD ON/OFF
System Navigation USB mouse, IR remote control, front panel buttons
Motion Area Setting Fixed Grid (22x18)
Sensitivity Levels
100
Firmware Upgrade Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization
Auto time sync by NTP server
23.4 Recording
Video Compression H.264 / H.265
Audio Compression G.711
Resolution 720p (1280×720), 1080p (1920×1080) ~ 4K-8MP
(3840×2160)
Record Rate
8 ch: 240fps@720p/1080p/3MP/4MP/8MP
16 ch: 480fps@720p/1080p/3MP/4MP/8MP
Recording Resolution Setting Per camera for different resolutions
#LX400078; r.36882/36882; en-US
153
