Lorex LNR600 Series User Manual

LNR600 Series System Specifications
23
Total PoE Power Output 130W (Max 25W per Camera)
Unit Weight (lbs / kg) 8ch: 5.1lbs / 2.6kg
16ch: 13.2lbs / 2.7kg
Unit Dimensions (W x H x D) 14.7 × 12.9 × 2.1” / 375 × 327 × 53mm
Operating Temperature 14° ~ 131° F / –10° ~ 55° C
Humidity 10 ~ 90% RH
23.9 Recording Resolution (Pixels) & Maximum Speed (FPS — Frames per
second)
Model
720p
1280x720
1080p
1920x1080
3MP
2048x1536
Super HD
4MP
2688x1520
4K
3840x2160
8ch
Total 240 240 240 240 240
Per channel 30 30 30 30 30
16ch
Total 480 480 480 480 480
Per channel 30 30 30 30 30
As our products are subject to continuous improvement, Lorex Corporation and its subsid-
iaries reserve the right to modify product design, specifications, and prices without notice
and without incurring any obligation. E&OE
#LX400078; r.36882/36882; en-US
