Chapter 8 LS Bus Protocol
8-5
8.2.2 Inverter continuous reading (R)
This is a function of continuous reading of designated amount of PLC data from designated address number.
 PC Request format
Format name Header
Station
No.
Command
Address of
inverter
Number of data
Frame
check
Tail
Frame (Example)
ENQ
H10
R
0100
H5
BCC
EOT
ASCII value
H05
H3130
H52
H30313030
H35
-
H04
Item Description
BCC
When ASCII value of each 1byte except ENQ and EOT is summed, the lowest 1byte of the
result value is BCC.
Device length
This specifies how many Words you will write. As converted value to ASCII, the range is from
H01 (ASCII value: 3031) to H08 (ASCII value: 3038).
Address of inverter
Enter the address that you want to read. ASCII value above 4 characters and non-numeric is
not allowed.
Note
• Device data of Word type is only supported.
