Appendix 3 Communication Error Code
A-12
Appendix 3 Communication Error Code
Appendix 3.1 XGT Server Error Code
Error code is displayed as hex 2 byte (4 byte as ASCII code). The user can see error by frame monitor
and in case of viewing by ASCII, the user can see the following error code.
Error code Error type
Error details and causes Example
0003
Number of blocks
exceeded
Number of blocks exceeds 16 at Individual
Read/Write Request
01rSS1105%MW10…
0004
Variable length
error
Variable Length exceeds the max. size of
16
01rSS010D%MW100000000
00..
0007
Data type error Other data type than X,B,W,D,L received
01rSS0105%MK10
Data length area information incorrect
01rSB05%MW10%4
In case % is unavailable to start with 01rSS0105$MW10
Variable’s area value wrong 01rSS0105%MW^&
0011
Data error
Other value is written for Bit Write than 00
or 01
01wSS0105%MX1011
0090
Monitor execution
error
Unregistered monitor execution requested
0190
Monitor execution
error
Reg. No. range exceeded
0290
Monitor reg. Error Reg. No. range exceeded
1132
Device memory
error
Other letter than applicable device is input
1232
Data size error
Request exceeds the max range of 60
Words to
read or write at a time.
01wSB05%MW1040AA5512
,..
1234
Extra frame error Unnecessary details exist as added.
01rSS0105%MW10000
1332
Data type
discordant
All the blocks shall be requested of the
identical
data type in the case of Individual
Read/Write
01rSS0205%MW1005%MB1
0
1432
Data value error Data value unavailable to convert to Hex
01wSS0105%MW10AA%5
7132
Variable request
area
exceeded
Request exceeds the area each device
supports.
01rSS0108%MWFFFFF
