Chapter 1 General
1.1 General
This user manual provides the information of Cnet I/F among XGB PLC system network about
specification/performance and how to operate.
Configuration of user manual is as follows.
Chapter Item Content
1 General Describes configuration of manual, product characteristic and term
2 Specification
Indicates general specification and performance specification of each module
used XGB PLC.
3 System configuration Describes basic communication parameter setting.
4 Basic setting Describes basic communication setting
5
Communication
function
Describes server for data communication between PLC and P2P parameter
setting.
6 Remote connection
Describes CPU connection method by communication channel through
XG5000, XG-PD.
7
XGT dedicated
protocol
Describes XGT dedicated communication frame structure.
8 Example program Describes example program for communication test.
9 Diagnosis function Describes about self diagnosis by XG-PD.
10
Installation and
wiring
Describes installation and wiring.
11 Maintenance Describes maintenance.
App.1 Term Describes term used in this manual
App.2 Flag list Describes parameter setting N area, flag L related with Cnet I/F.
App.3
Communication error
code
Describes XGT server, modbus server, P2P error code.
App.4 Dimension Describes dimension of communication module.
