Chapter 8 LS Bus Protocol
8-2
2) Command frame sequence
▪ Sequence of command request frame
ENQ
Station
No.
Command Formatted data BCC EOT
ACK
Station
No.
Command Formatted data BCC EOT
NAK
Station
No.
Command Formatted data BCC EOT
8.1.2 List of commands
List of commands used in LS Bus communication is as shown below.
Items
Command
Treatment
Command type
Code ASCII code
Continuous read R H52 Read inverter variable of Word.
Continuous write W H57 Write inverter variable of Word.
(Inverter ACK response)
(Inverter NAK response)
