Chapter 11 Diagnosis
11-1
Chapter 11 Diagnosis
With XG-PD used, the status of the system and the network can be checked and diagnosed.
Diagnosis function is composed as described below
▶ CPU module information
▶ Communication module information
▶ Frame monitor
▶ Status by service
11.1 Diagnosis Function of XG-PD
How to diagnosis system and network status by XG-PD system diagnosis are described below.
Connect XG-PD to loader port of main unit and if you select “Online -> System Diagnosis”, the following
window is created.
[Figure 11.1.1] System diagnosis window
• Select [Online] – [System Dianosis] and click the icon ( ).
• Click the right button on the the relevant module and click Frame Monitor or Status By Service to check.
