Chapter 10 Example Program
10-8
10.2.2 Settings of XGT client
To operate XBL-C21A of client as XGT client, set Cent I/F module as follows.
1. Select [Online]-[Connection settings] or click icon ( ).
2. After setting the connection option according to user, click the ‘connection’.
Select [Online]-[Read IO Information] and click icon ( ).
IO information of currently mounted is shown on the project window.
Select XBL-C21A and set standard setting at channel 2 to be same with setting
described in [Table 10.2.1].
2. In case of acting as client, station setting doesn’t have the meaning so set temporary
station (0~255).
3. When acting as client, active mode should be [Use P2P settings].
To Next Page
