LSIS XBL-C41A User Manual

Chapter 7 XGT Dedicated Protocol
7-4
7.1.4 Data type
It’s possible to read and write device in built-in communication. When device is used, be aware of data type.
 Data type of device
• Available types of device
- XBM-DXXXS and XBC-DXXXH
Device “S” type range “H” type range Size (Word) Remark
P P0 – P127 P0 – P1023 1024
Read/Write/Monitor available
M M0 – M255 M0 – M1023 1024 Read/Write/Monitor available
K K0 – K2559 K0 – K4095 4096 Read/Write/Monitor available
F F0 – F255 F0 – F1023 1024
Read/Monitor available
T T0 – T255 T0 – T1023 1024 Read/Write/Monitor available
C C0 – C255 C0 – C1023 1024 Read/Write/Monitor available
L L0 – L1279 L0 – L2047 2048 Read/Write/Monitor available
N N0 – N3935 N0 – N5119 5120
Read/Monitor available
D D0 – D5119 D0 – D10239 10240 Read/Write/Monitor available
U U00.00 – U07.31 U00.00 – U0A.31 352 Read/Write/Monitor available
R - R0 – R10239 10240 Read/Write/Monitor available
- XEC-DXXXH
Device Range Size (Word) Remark
I %IW0.0.0 ~ %IW15.15.3 1024
Read/Write/Monitor available
Q %QW0.0.0 ~ %QW15.15.3 1024 Read/Write/Monitor available
M %MW0 ~ %MW8191 8192 Read/Write/Monitor available
W %WW0 ~ %WW10239 10240 Read/Write/Monitor available
R %RW0 ~ %RW10239 10240 Read/Write/Monitor available
F %FW0 ~ %FW1023 1024 Read/Monitor available
K %KW0 ~ %KW4095 4096 Read/Write/Monitor available
L %LW0 ~ %LW2047 2048 Read/Write/Monitor available
N %NW0 ~ %NW5119 5120
Read/Monitor available
U %UW0.0.0 ~ %UW0.15.31 512 Read/Write/Monitor available
