LSIS XBL-C41A User Manual

Chapter 10 Example Program
10-2
Sequence
Procedure
Setting method
4
Selecting
the active
mode
1. Select active mode of server for user to use.
2. XGB Cnet I/F module supports XGT server, Modbus ASCII server, Modbus
RTU server.
5
Writing
parameter
1. Select [Online] – [Write Parameter] or click icon ( )
2. Click [OK].
3. If you click [OK] button, parameter is sent to PLC.
If you don’t reset relevant module, XGB Cnet I/F module acts as changed parameter.
6
Checking
the
operation
1.
Select [Online] – [System Diagnosis] or click icon ( ).
2. Click the right button on the relevant module and click Frame Monitor or Status By
Service to check
