(2) Extension Cnet performance specification
XGB extension Cnet communication module performance specification is as follows
Item
Specification
XBL-C21A
XBL-C41A
Serial communication
channel
RS-232C 1 channel RS-422(485) 1 channel
Modem connection
function
External modem connection available -
Operation
mode
(Operation
definition
by port)
P2P
Operates as communication client
- XGT dedicated protocol client
- Modbus ASCII/RTU client
- User defined communication
- LS Bus Client
Server
- XGT dedicated protocol server
- Modbus ASCII/RTU server
Data
type
Data bit
7 or 8
Stop bit
1 or 2
Parity
Even/Odd/None
Synchronization type
Asynchronous type
Transmission speed
(bps)
1200/2400/4800/9600/19200/38400/57600/115200 bps available
Station No. setting
Setting range: 0~255
Max. station No. available: 32 stations
Transmission
distance
RS-232C: 15m
(Extension available in case of using
modem)
RS-422/485: max 500m
Diagnosis function Check available by LED and XG-PD diagnosis service
Consumption current
120mA
120mA
Weight
56g
56g
