LTS LTD8516K-ST - Chapter 2 Getting Started; Start Up the Device; Activate the Device

Network Video Recorder User Manual
32
No.
Item
Description
D+, D- pin connects to Ta, Tb pin of controller. For cascading devices, the
first DVR’s D+, D- pin should be connected with the D+, D- pin of the next
DVR.
Connector for alarm input.
Connector for alarm output.
7
RS-232 Interface
Connector for RS-232 devices.
8
VGA Interface
VGA video output connector. Display local video output and menu.
9
eSATA
Connects external SATA HDD, CD/DVD-RW.
10
HDMI1 Interface
HDMI1 video output connector. Display local video output and menu.
11
HDMI2 Interface
HDMI2 video output connector.
12
Network
Interface
Connector for network.
13
USB Interface
Universal Serial Bus (USB) port for additional devices.
14
GND
Ground
15
Power Supply
100 to 240 VAC power supply.
16
Power Switch
Switch for turning on/off the device.
17
AUDIO IN
DB26 female head
