Page 8-4 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
Boots, Protective
Rubberized protective boots are installed on the top and bottom of all current versions of
LTV
®
ventilators to protect against accidental shocks and strikes to the casing.
This section is divided into four sub-sections to accommodate the removal, replacement, or
installation of the boots under the following conditions:
• Temporary Removal (to allow removal of the back panel)
• Permanent Removal (for permanent removal of the boots)
• Reinstallation (to reinstall boots after ventilator maintenance)
• New Installation (to install new boots where they were not previously installed)
WARNING
Mounting Screw Use – Internal damage to the ventilator may result if the wrong length
mounting screws are used when installing or removing external accessories.
Accessory Mounting Screws - Refer to the information supplied with the replacement
screws kit, P/N 11149, to determine the appropriate screws to use when removing or
exchanging external accessories on an LTV
®
1200/1150 ventilator.
