LTV 1150 - Transducer Calibration, Acceptable A;D Counts

Page E-16 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
Transducer Calibration, Acceptable A/D Counts
Airway Pressure (AP)
@ 50 cmH
2
O 733 – 1570
Ambient 35-350
Flow Differential Bi-Directional (FDb)
@ -30 cmH
2
O 64-3240
Ambient 3180-4045
Flow Differential Wide (FDw)
@ 30 cmH
2
O 854 – 4030
Ambient 10 – 400
Flow Differential Narrow (FDn)
80 ± 70 10 - 150
Ambient 128-3968
4015 ± 70 3945 - 4085
Ambient 128-3968
Flow Valve Differential (FVd)
@ 15 cmH
2
O 1915 – 2340 (For Software Version < 5.04)
1915 – 2521 (For Software Version ≥ 5.04)
Ambient 40 – 328
PEEP Pilot Pressure (PPP)
@ 30 cmH
2
O 999 – 2493
Ambient 135 – 272
Oxygen Pressure (O
2
) (LTV
®
1200 only)
@ 50 PSI 900 – 1822
Ambient 122 – 246
