LTV 1150 - Turbine Manifold

p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page 8-127
Turbine Manifold
Parts required for replacement: Tools required:
• Turbine Manifold Assembly P/N 11490
• Cable Tie P/N 10466
• O
2
Donut Seal P/N 10603
• Silicone Gel Lubricant P/N 10123
62
• RTV Silicone Adhesive P/N 10122
Replace if damaged:
• Thermo Conductive Pad P/N 10129
• Sealing Gasket P/N 10175
• Damping Grommets (4) P/N 10266
• Grounding Clips (4) P/N 10752
• Green O
2
Port Cover (O
2
Block) P/N 14446
• Phillips screwdriver with torque
meter
• Grounded anti-static wrist strap
• Small dykes or cutters
• Mild cleanser
• Cable tie tool
• Flow Valve Insertion Tool (Mylar)
P/N 14206
• Torque screwdriver
(120 in-oz/o.84 Nm)
When replacing the turbine manifold assembly, it is easiest to remove several components
and replace them together. These will be done in the following order:
• Remove the back panel and disconnect the battery
• Remove the left soft side
• Remove the motor board
• Remove the flow valve
• Remove the turbine manifold and oxygen blender as a unit
• Disconnect the oxygen blender (LTV
®
1200) or O
2
Block (LTV
®
1150) from the turbine
manifold
• Connect the new oxygen blender (LTV
®
1200) or O
2
Block (LTV
®
1150) to the turbine
manifold
• Replace the oxygen blender (LTV
®
1200) or O
2
Block (LTV
®
1150) and turbine manifold
as a unit
• Replace the flow valve
• Replace the motor board
• Replace the left soft side
• Reconnect the battery and replace the back panel
62
In the European Union, Loctite® 8104 may be substituted as an equivalent compound.
