LTM/LTV mounting assembly installation and removal
Parts Required for Installation: Tools required:
Components
The current LTM™ to LTV
®
mounting assembly, p/n
17916-001, which contains:
• LTM™ to LTV
®
mounting bracket (1), p/n 17918-001
• LTM™ to LTV
®
mounting block (1), p/n 17917-001
• LTV
®
external accessories screw kit (1), p/n 11149
• #4-40 X 3/8” pan-head mounting screws (5), p/n
10879
• #4-40 X 5/16” pan-head mounting screw (1), p/n
11356 (not needed for the LTV
®
1200/1150)
• Instruction sheet, LTM™ to LTV
®
mounting bracket
(1), p/n 18081-001
• Phillips screwdriver
with torque meter
• 7/64” Allen wrench
In order to accommodate an LTM™ Graphics Monitor, an LTM/ LTV
®
mounting assembly
must be attached to the LTV
®
1200/1150 ventilator.
To access internal components of the LTV
®
ventilator for service, the mounting bracket must
be removed.
This section is divided into four sub-sections to accommodate the removal, replacement, or
installation of the LTM/ LTV
®
mounting bracket under the following conditions:
• Temporary Removal (to allow removal of the back panel for access)
• Permanent Removal (to permanently remove the bracket)
• Reinstallation (to replace bracket after ventilator maintenance)
• Installation (if a mounting assembly was not previously installed)
