Page 8-10 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
Boots, Reinstallation
Parts required for replacement: Tools required:
• Replacement Screws Kit, 11149
Replace if damaged:
• Finish Washers (6) P/N 10191
29
,
or 19119-001, or 19119-002
• Phillips screwdriver with
torque meter
To reinstall the Upper Protective Boot
30
:
1) Carefully place and support the disconnected ventilator in an upright position on a
clean, dry surface.
2) Orient the upper protective boot over the ventilator as shown in the illustration on the
next page. Move the boot down into position on the top of the ventilator and align its
four screw holes with the corresponding holes in the ventilator back and side panels.
3) Insert and thread two 1/2” 4-40 flat-head mounting screws with finish washers through
the screw holes in the sides of the upper boot, as indicated in the illustration on the next
page.
4) Insert and thread two 3/8” flat-head mounting screws, with finish washers, through the
screw holes in the legs of the upper boot, as indicated in the illustration on the next
page.
WARNING
Specific boot screw location –Using a screw of the wrong length in this location can cause
the ventilator to malfunction resulting in possible harm to the patient.
29
Contained in Pulmonetic Systems Replacement Screws Kit, P/N 11149
30
See Appendix E - Reference Information,
External Accessories Screw Location, Type and Length for additional information.
