LTV 1150 - Settings, Front Panel Controls and Extended Features

p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page E-11
Settings, Front Panel Controls and Extended Features
The following tables provide factory default information.
Control - Default Control - Default
Breath Rate - 12 bpm O
2
% (O
2
Flush) - 21%
Control Lock - On PEEP - 0 cmH
2
O
Data Display Scrolling - Auto-On Pressure Control - 1 cmH
2
O
High Pressure Limit - 20 cmH
2
O Pressure Support - 1 cmH
2
O
Inspiratory/Expiratory Hold - Off Sensitivity - 2 Lpm
Inspiratory Time - 1.5 sec Tidal Volume - 500 ml
Low Minute Volume - 2.5 Lpm Ventilation Mode - Assist/Control
Low Pressure - 5 cmH
2
O Volume Pressure Mode - Volume
Low Pressure O
2
Source - Off
The factory-set default Extended Features settings are:
Feature
- Default Feature - Default
Alarm Volume - 85 dBA Patient Query - On
Apnea Interval - 20 sec Patient Size - Infant
Com Setting
83
- Data PC Flow Termination - Off
Control Unlock - Easy PIP LED - On
Date Format - MM/DD/YYYY Rise Time Profile - 4
High f Alarm - High f Off SBT Display f/Vt - On
High f Alarm Delay -
30 sec SBT FIO
2
- 21%
High PEEP Alarm -
PEEP +5 cmH
2
O SBT High f Alarm - 35 bpm
HP Alarm Delay - No Delay SBT High f/Vt Alarm - 105 bpm / l
Language - English SBT Low f Alarm - 10 bpm
Leak Compensation - On SBT Low f/Vt Alarm - 70 bpm / l
Low PEEP Alarm - PEEP -5 cmH
2
O SBT Mode - Off
LPP Alarm - All Breaths SBT Mode Run Time - 20 min
NPPV Mode - Off SBT PEEP - 0 cmH
2
O
O
2
Duration Cylinder -
2000 psi or 138 bar SBT Pressure Support - 10 cmH
2
O
O
2
Duration Cylinder -
622 liters Variable Flow Termination - 25%
O
2
Flush Period - 3 min Variable Time Termination - 1.5 sec
Patient Assist - Normal
83
This feature is not reset to default values when the SET DEFAULTS option is used in Extended Features.
