p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page 9-1
Chapter 9 -
F
INAL
C
HECKOUT
T
EST
This section provides a set of checkout tests that should be performed after modifications
have been made to the ventilator. Checkout worksheets are provided after the test
instructions for recording the results of each checkout test.
Checkout Test Selection
The following matrix shows what tests should be performed based on what parts have been
replaced. Note that Calibration and Power Checkout must be done while the back panel is
off the ventilator. No checkout tests are required when changing the External Inlet filter, the
O
2
Inlet filter, and the fan filter.
Part Replaced
Calibration
Required
Power
Checkout
General
Checkout
Performance
Checkout
12 Hour
Burn-in
Alarm Sounder
X
Analog Board Assembly
X X X X X
Fan Assembly
X X
Flow Valve Assembly
X X X X
Front Panel
X X X
Interior Inlet filter
X
Internal Battery Pack
X
64
Internal Flexible Tubing
X
X X
Main Board Assembly
X X X X X
Membrane/Overlay
X X X X X
Memory Board Assembly
X X X X
Motor Board Assembly
X X X X
O
2
Blender Assembly
X X X X
Pigtail
X X X X
Power Board Assembly
X X X X X
Rotary Knob Assembly
X X
Solenoid Manifold
X X X X
Thermo Conductive Pad
X
Turbine Manifold
X X X
Ventilator Back Panel
X
64
When replacing the Internal Battery, only Power Checkout test steps 2A and 2B are required to be performed.
