p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page 8-121
22) Reconnect the 4-wire flow valve connector to the motor board and the 2-wire flow valve
Thermistor cable to the power board. The connectors are keyed to fit in only one
direction and will snap into place when properly connected.
23) Install an O
2
Sampling Tube
59
. See Back Panel, Reinstallation in Chapter 8 –
Component Removal and Replacement for detailed instructions.
24) Verify that no tubing is kinked or twisted, and that it will not be pinched when
compressed by the back panel. Refer to the routing instructions, tables and diagrams
beginning on page 8-33 to check the tubing routing. Always check ALL tube routing
for kinks or compression that might result in restricted flows prior to closing the
ventilator.
25) Reconnect the internal battery and replace the back panel (see page 8-29).
59
O
2
Sampling Tube, P/N 10544, ~10.0” long, 0.125” O.D. X 0.079 I.D. clear polycarbonate tubing.
