Page D-2 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
5) Press Select and
xx:eventdate is displayed.
xx is the chronological number of the event occurrence.
eventdate is the date of the event; the date of the first occurrence is displayed in
the initial occurrence recordings and the date of the latest occurrence
in the secondary occurrence recordings of the same type of event.
Date is displayed in the currently selected date format.
6) Press Select again,
xx:hh:mm:ss is displayed.
xx is the chronological number of the event occurrence.
hh:mm:ss is the time of the first occurrence; the time of the first occurrence is
displayed in the initial occurrence recordings and the time of the latest
occurrence in the secondary occurrence recordings of the same type
of event.
7) Press Select,
xx:data is displayed.
xx is the chronological number of the event occurrence.
data is the data associated with the event; the data associated with the first
occurrence is displayed in the initial occurrence recordings and the
data associated with the latest occurrence in the secondary
occurrence recordings of the same type of event.
NOTE
For some events, the data field will be blank.
8) Press the Select button to return to the initial display.
9) Turn the Set Value knob clockwise or counterclockwise to view other events.
10) To exit the EVENT TRACE, turn to EXIT and press the Select button or press Control
Lock.
For more information about how these codes are used, see the LTV
®
1200 or the LTV
®
1150
Ventilator Operator’s Manual or contact your Service Representative.
