Table 3.14-1 — VT100 Settings For Cajun Switch Replacement Procedure
Setting Value
Terminal Emulation VT100
COM Port Com 1 (or some other serial connector)
Baud Rate 9600
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
• A flat-head screwdriver.
• A Philips #1 screwdriver.
• For direct Console communications, connect the Cajun P330 to the Console
Terminal using the supplied RJ-45 crossed cable and RJ-45 to DB-9 adapter.
NETWORK PROCEDURES
Procedure 3.14
235-200-150
October 2004
Page 3.14-2 Issue 3.00L
