5.10 Activate/Deactivate Balance Feature
OVERVIEW
This procedure activates the ability to provide data for blocked-call identification on
analog line units (LU1, LU2, and LU3) in a switching module. The data (high CCS
users that cause blocking) is delivered to the Administrative Module (AM) by human
machine messages. But to collect the data the balance feature must be activated.
The balance data may be directed to either the TTY port or the 3B21 emulator log
files. Activity in the ECD accomplishes this. It is assumed the TTY port has already
been defined in the ECD.
Once the ECD is populated, the balance feature is activated, deactivated, and
re-activated with Recent Change/Verify (RC/V). The ECD update is a one-time effort.
There are variations in the software release. These differences are noted in the
procedure.
PROCEDURE
1. Select the type of activity to be performed from Table 5.10-1.
Table 5.10-1 — Activate/Deactivate Balance Feature Activity Selection
Activity Go to...
First time activation with data directed to 3B21 emulator log
file.
Subprocedure
5.10.1
First time activation with data directed to non-balance specific
TTY Port.
Subprocedure
5.10.2
Activate balance session Subprocedure
5.10.4
Deactivate balance session Subprocedure
5.10.5
235-200-150
January 2003
ROUTINE MAINTENANCE
Procedure 5.10
Issue 3.00 Page 5.10-1
