Table 2-4 — Terminal Interface Devices
Name Description Document
TRAFFPRT Local Traffic Measurements Channel 235-070-100A1
235-105-231
OFFRECRPT On-line Office Record Print Channel is
used to print office record forms.
235-118-2XX
235-900-304
CALEASAS Electronic Surveillance Terminal 235-200-400
235-200-410
CALEAPRT Electronic Surveillance Printer 235-200-400
235-200-410
2.9.1 Serial Interface
The DRM uses a serial adapter card to interface multiple serial devices such as
terminals and printers to the AW.
The serial card is equipped in the AW as follows:
• PCI slots (Netra 240) – PCI slot 1 is equipped with a Serial Asynchronous
Interface (SAI) card that provides 8 serial ports for terminal and printer
connections. PCI slot 0 is equipped with a second SAI card that supports 8
terminal and printer connections.
• PCI slots (Netra t 1120 and Netra 20) – PCI slot 2 is equipped with a Serial
Asynchronous Interface (SAI) card that provides 8 serial ports for terminal and
printer connections. PCI slot 1 can be equipped with an optional second SAI card
that supports 8 terminal and printer connections.
Figures 2-16, 2-17 and 2-18 provide illustrations of a Supplemental Trunk Line
Workstation (STLWS) and ROP connected to the AW system unit. While these figures
show the STLWS attached to a specific port, a terminal device can occupy any
available non-reserved port. Tables 2-5 and 2-2 list the serial port assignments for
terminal devices.
5ESS
®
SWITCH DISTINCTIVE REMOTE MODULE 235-200-150
Feburary 2007
Page 2-22 Issue 3.00O
