BIT 2: EAEN - Indicates a force function to the AM is
active or the IPB is non-zero.
BIT 1: FBDP - Indicates that a subsequent system bootstrap
will be forced from the primary boot device.
BIT 0: FBDS - Indicates that a subsequent system bootstrap
will be forced from the secondary boot device.
Digit 19 = EAI status digit.
The bits are numbered from right to left as follows:
BIT 3 2 1 0
BIT 3: FONL - Indicates the AM central control (CC) associated
with the EAI is to remain the on-line CC. The
mate CC will concurrently be forced off-line (FOFL).
BIT 2: FOFL - Indicates the AM CC associated with the EAI is
to remain the off-line CC. The mate CC will
concurrently be forced on-line (FONL).
CC
FORCED
ON-LINE
CC
FORCED
OFF-LINE
TIMER
DISABLED
CC
MRF
HARDWARE STATUS BITS (4 of 6)
Figure A2-1 — Hardware Status Bits (4 of 6)
235-200-150
January 2003
APPENDIX 2
PROCESSOR RECOVERY MESSAGES
Issue 3.00 Page A2-23
