MacDon DWA - Page 101

REPAIR PARTS
Ref Part Number Description Qty
Serial
Number
1 139508
MANIFOLD – DWA
DRIVE, SEE NEXT PAGE FOR
SERVICE PART
S
1
2 139974
VALVE BLOCK AUX LIFT, SEE NEXT PAGE FOR SERVICE
PARTS
5
1
3 144807
HOSE – HYDRAULIC
1
4 21843
FITTING – E
LBOW 90° HYDRAULIC 1
5
50221
FITTING – ELBOW 90° H YDRAULIC
2
6 50102
FITTING – HYDRAULIC TEE
2
7
21830
FITTING
– HYDRAULIC CONN ECTOR 1
8 30695
FITTING – HY DRAU LIC CONN ECTOR
2
9 30282
FITTING – ELBOW 90° H YDRAULIC
2
10 30556
FITTI
NG – ELBOW 90° HYDRAULIC 1
11 118084
FTG – HYDRAULIC REDUCER
1
12 30994
PLUG – HEX CW O-RING
2
13 132867
HOS
E – HYDRAULIC 2
14 176077
HOSE – HYDRAULIC
1
15 50104
FITTING – ELBOW 90° H YDRAULIC
1
16 144805
H
OSE – HYDRAULIC 1
17 144806
HOSE – HYDRAULIC
1
18 21805
FITTING – ELBOW HYDRAULIC
1
19 REF MOTOR – SEE DRAPER AND DECK
20 REF
CYLINDER – SEE DECK SUPPORTS AND LINKAGE
21 109575
SWITCH – R OC KER, MOM-OFF-MOM
1
22 109718 GAUGE – POTENTIOMETER 1
23 138691
KNOB – SPEED CONTROL
1
24 21821
BOLT – HH FLG (SERR FACE) 3/8 NC x 0.75 GR 5 ZP
2
5. Refer to service bulletin sb #1210 regarding software update required.
214049 93 Revision A
