MAINTENANCE AND SERVICING
4.1.6 Adjusti
ng Rear Deflector
The rear deflec
tor (A) prevents crop from entering inside
draper. To ad
just the rear deflector, follow these steps:
1. Loosen all ei
ght nuts (B) along the length of the deck.
2. Set the defle
ctor he ight (C) t o be 1.5–8 mm
(1/16–5/16
in.) above the draper.
3. Tighten nut
s(B).
Figure 4.9: Draper Deck Cross Section
4.1.7 Maintaining the Draper Roller
The dr
aper rollers have non-greaseable bearings. The external seal should be checked every 200 hours or more
frequ
ently in sandy conditions to obtain the maximum bearing life. Remove front skid to inspect seals.
Remo
ving and Reinstalling the Drive Roller
DAN
GER
To avoid bodily injury or death from unexpected start-up or fall of raised machine, stop engine, remove
key and engage safety pin before going under machine for any reason.
214049
71
Revision A
