MAINTENANCE AND SERVICING
4.2 Lubricating the Double Windrow Attachment
Grease the following five pivot points (A) every 250 hours and/or at the end of each season.
Figure 4.21: Deck Pivot
Figure 4.22: Linkage Pivot
Fi
gure 4.23: Linkage Pivot: Bottom View of DWA
214049 76 Revision A
