OPERATION
Forming shield settings
• Make sure forming shield (B) is installed correctly with
bracket (A).
• Buildup of sticky crop residue on deflec tor sliding
surfaces should be periodically removed.
• Refer to 3.7 Positioning the Conditioner Forming Shield,
page 62.
Figure 3.18: Forming Shield
214049 66 Revision A
